Ruthmann T510 HF

Ruthmann T510 HF

Ruthmann T510 HF

Specification

Make
Make
Ruthmann
Model
Model
T510 HF
Working Height
Working Height
51m / 167ft 4in
Platform Height
Platform Height
49m / 160ft 10in
Maximum Outreach
Maximum Outreach
33m / 108ft 4in
Min Weight
Min Weight
18,000.00kg / 39,780lbs
Safe Working Load
Safe Working Load
600.00kg / 1,326lbs
Machine Length
Machine Length
10.4m / 34ft 2in
Machine Height
Machine Height
3.75m / 12ft 4in
Power Options
Power Options
Diesel
Cage Rotation
Cage Rotation
440 degrees

Interested in hiring a Ruthmann T510 HF?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Key Features Accessories Ideal Applications Overview Resources

Ruthmann T510 HF Vehicle Mounted Platform

The Ruthmann T510 HF is a 2-axle chassis truck mounted platform with an impressive 51m working height and 33m outreach.

Working at significant heights presents unique challenges, including safety concerns, limited access, and operational inefficiencies. Traditional access equipment often falls short, leading to project delays and increased risks. The Ruthmann T510 HF addresses these challenges head-on. Its exceptional reach and high load capacity of 600kg ensure safe and efficient access to elevated work areas. The compact design and advanced boom technology provide unparalleled manoeuvrability and stability, enabling you to tackle complex tasks with confidence.

This chassis-mounted aerial work platform is an invaluable asset across various sectors:

  • Utilities: Facilitates maintenance of power lines, water towers, and gas pipelines with ease
  • Telecommunications: Enables installation and servicing of communication masts and antennas
  • Construction: Assists in high-rise building projects, roofing, and structural inspections.
  • Facilities Maintenance: Ideal for servicing tall structures, lighting systems, and signage
  • Arboriculture: Supports tree care operations, including pruning and canopy access

Designed with the operator in mind, the platform features automatic setup and retraction mechanisms, reducing preparation time and increasing operational efficiency. The maintenance-friendly design further minimises downtime, keeping your projects on track. Choose the high-performance Ruthmann T510 HF Vehicle Mounted Platform, engineered for any tasks demanding exceptional reach and precision.



Key Features of the Ruthmann T510 HF

  • 51m working height
  • 33m outreach
  • Generous 600kg working cage load capacity
  • 180° Swivelling angle of upper boom
  • 220° Swivelling angle of the jib
  • 500° Main Turret rotation
  • 10.4m total vehicle length for manoeuvrability in restricted areas (depends on the vehicle type)
  • Top performance data due to multi-bevelled boom technology
  • Standing’ working basket perfect for ‘under and up’ as well as all possibilities of ‘up and over and back’ during lowered RÜSSEL®
  • Working below ground possible
  • Automatic set-up/retraction mechanism at the push of a button
  • Spacious working cage: 2.42 x 0.97m that can be extended hydraulically to 3.82 x 0.97m
  • Maintenance-friendly boom system
  • User-friendly operation

Recommended training course for this platform: IPAF Category: Static Boom (1b)

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.



Looking for something else?

Discover our entire range of Vehicle Mounted Platforms here.

  • Changing locations
  • General building maintenance
  • Film/TV work
  • Window cleaning
  • Construction
  • Industries and factories
  • Airports
  • Railways
  • Ventilation systems
  • Electrical systems
  • Advertising signs
  • Guttering
  • Painting
  • Lighting
  • Industrial Maintenance
  • Assembly
  • Ports
  • Pruning
  • Industrial cleaning
  • Restorations
  • Tree Care
  • Facade Cleaning
  • Arborist
  • CCTV/Security
  • Energy
  • Facilities Maintenance
  • Highways
  • Roofing
  • Telecommunication
  • Utilities

The Ruthmann T510 HF can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Boom Lift Pipe Racks

Boom Lift Pipe Racks
Harness

Harness
Telematics

Telematics
Tool Tethers

Tool Tethers
Transformer & Lead

Transformer & Lead
Outrigger Pads

Outrigger Pads

The Ruthmann T510 HF comes equipped with various features designed to enhance your efficiency and performance on the job.

Diesel Powered

Diesel Powered
Stage V Engine

Stage V Engine
Power to Platform

Power to Platform
Extra Capacity

Extra Capacity

Interested in hiring a Ruthmann T510 HF?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
