Sinoboom AB46RJ

Sinoboom AB46RJ

Sinoboom AB46RJ

Specification

Make
Make
Sinoboom
Model
Model
AB46RJ
Working Height
Working Height
48.6m / 159ft 6in
Platform Height
Platform Height
46.6m / 152ft 11in
Maximum Outreach
Maximum Outreach
25.5m / 83ft 8in
Min Weight
Min Weight
27,300.00kg / 60,333lbs
Safe Working Load
Safe Working Load
455.00kg / 1,006lbs
Machine Length
Machine Length
15m / 49ft 3in
Machine Width
Machine Width
2.49m / 8ft 3in
Machine Height
Machine Height
3.2m / 10ft 6in
Power Options
Power Options
Diesel
Turning Radius
Turning Radius
7.1m / 23ft 4in
Gradeability
Gradeability
40%
Cage Rotation
Cage Rotation
180 degrees

Interested in hiring a Sinoboom AB46RJ?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Key Features Accessories Ideal Applications Overview Resources

Sinoboom AB46RJ 48.6m Diesel Articulated Boom Lift

The Sinoboom AB46RJ has a maximum working height of 48.6m, a maximum outreach of 25.5m with an unrestricted platform capacity of 275kg, or just under 24m with a maximum capacity of 455kg. It features an up & over reach of around 19m, thanks to the three section telescopic riser and three section top boom, plus an articulating jib that also offers up to 150 degrees of rotation.

The overall stowed width of this machine is 2.49m and the overall length is 15m, or 12.3m with the jib tucked away for transport. It has an overall height of 3.2m and weighs 27,300kg.

The Sinoboom AB46RJ boasts an EU Stage V diesel engine, along with a number of other refinements and improvements, including the switch from all steel superstructure covers/shrouds to a heavy duty, but lighter composite material.

Key Features of the Sinoboom AB46RJ

  • 4WD x 4WS Proportional control with 3 joysticks with variable proportional control, accuracy in reaching the operation target
  • Industry leading 7" screen displays faults and status information, for easy reference, reducing service technician assistance allowing workers to complete tasks under the remote guidance of qualified service technicians
  • The working platform can be lifted and lowered to any position without the need to operate the folding arm
  • 4-wheel brake Hydraulic platform levelling
  • Weighing system
  • Tilt protection system
  • Max tilt rating to 5°
  • Emergency stop and lowering system
  • Flashing beacon
  • Horn & buzzer
  • 2.44m x 0.91m platform size
  • Fault diagnosis system
  • Rough Terrain Foam-filled tires

Recommended training course for this platform: IPAF Category: Mobile Boom (3b)

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Cherry Pickers/Boom Lifts here.

  • General Construction
  • Cladding Works
  • Industrial & Venue
  • Petrochemical
  • Shipyards & Ports
  • Infrastructure

The Sinoboom AB46RJ can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Boom Lift Pipe Racks

Boom Lift Pipe Racks
Chalwyn Valves

Chalwyn Valves
Ground Guards

Ground Guards
Harness

Harness
Nappies

Nappies
Onboard Generator

Onboard Generator
Telematics

Telematics
Tool Tethers

Tool Tethers
Wheel Covers

Wheel Covers

The Sinoboom AB46RJ comes equipped with various features designed to enhance your efficiency and performance on the job.

Diesel Powered

Diesel Powered
Power to Platform

Power to Platform
Rough Terrain Tyres

Rough Terrain Tyres
Extra Capacity

Extra Capacity
Stage V Engine

Stage V Engine
Four Wheel Drive

Four Wheel Drive
Four-Wheel Steering

Four-Wheel Steering
Crab Steering

Crab Steering
