Tractor Mounted Ascendant A22-17

Tractor Mounted Ascendant A22-17

Tractor Mounted Ascendant A22-17

Specification

Make
Make
Ascendant
Model
Model
A22-17
Working Height
Working Height
21.4m / 70ft 3in
Platform Height
Platform Height
19.4m / 63ft 8in
Maximum Outreach
Maximum Outreach
17.5m / 57ft 5in
Min Weight
Min Weight
9,000.00kg / 19,890lbs
Safe Working Load
Safe Working Load
280.00kg / 619lbs
Machine Length
Machine Length
7.2m / 23ft 8in
Machine Width
Machine Width
3.8m / 12ft 6in
Machine Height
Machine Height
3.8m / 12ft 6in
Power Options
Power Options
Diesel
Turning Radius
Turning Radius
4.5m / 14ft 10in
Gradeability
Gradeability
160%
Cage Rotation
Cage Rotation
160 degrees

Interested in hiring a Tractor Mounted Ascendant A22-17?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Key Features Accessories Ideal Applications Overview Resources

Tractor Mounted Ascendant A22-17 Diesel Extreme Terrain Vehicle

The Tractor Mounted Ascendant A22-17 gives a working height of 22m and offers a 135 horse powered John Deere which gives the operator excellent off road abilities. It also offers a forward speed range from 0.5kph to 40kph and gives excellent control off road as well as fully road legal performance on the highway. The tractor mounted MEWP offers an horizontal outreach of 17.5m, all with an unrestricted safe work load of 280kg. The fly boom is 2.4m long and has an operating arc of 125 degrees as well as being equipped with a 10,000kg winch with-spade type anchor.

Key Features of the Ascendant A22-17

  • Direct hydraulic proportional controls at cage and base
  • 160 degree powered cage rotation
  • Four H-type hydraulic stabilisers
  • Three section all steel telescopic boom
  • 2.4m long jib with 125 degree working arc
  • Structural quality tubular aluminium cage
  • DC powerpack and handpump for emergency lowering
  • Warning lights for booms not stowed, stabilisers not stowed, cab protection area and stabiliser mode
  • Typical Carriers of the Ascendant A22-17 are John Deere 6620 and Deutz 620

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Extreme Terrain Vehicles here.

  • Overhead power line installation, maintenance and repair
  • Slopes, both internal and external
  • Muddy, soft ground
  • Tunnelling
  • Horticulture
  • Arboriculture
  • Estate management

The Tractor Mounted Ascendant A22-17 can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Boom Lift Pipe Racks

Boom Lift Pipe Racks
Outrigger Pads

Outrigger Pads
Seatbelt Warning Beacon

Seatbelt Warning Beacon
Telematics

Telematics
Tool Tethers

Tool Tethers
24ft Trailer

24ft Trailer
25ft Trailer

25ft Trailer
30ft Trailer

30ft Trailer
36ft Trailer

36ft Trailer

The Tractor Mounted Ascendant A22-17 comes equipped with various features designed to enhance your efficiency and performance on the job.

Diesel Powered

Diesel Powered
Four Wheel Drive

Four Wheel Drive
Rough Terrain Tyres

Rough Terrain Tyres
