A18-13TJ Swampmaster

A18-13TJ Swampmaster

A18-13TJ Swampmaster

Specification

Make
Make
Ascendant
Model
Model
A18-13TJ
Working Height
Working Height
18m / 59ft 1in
Platform Height
Platform Height
16m / 52ft 6in
Maximum Outreach
Maximum Outreach
13m / 42ft 8in
Min Weight
Min Weight
5,500.00kg / 12,155lbs
Safe Working Load
Safe Working Load
230.00kg / 508lbs
Machine Length
Machine Length
6.9m / 22ft 8in
Machine Width
Machine Width
2.3m / 7ft 7in
Machine Height
Machine Height
3.46m / 11ft 5in
Power Options
Power Options
Diesel
Turning Radius
Turning Radius
Zero
Gradeability
Gradeability
33%
Cage Rotation
Cage Rotation
160 degrees

Interested in hiring a A18-13TJ Swampmaster?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Key Features Accessories Ideal Applications Overview Resources

A18-13TJ Swampmaster Extreme Terrain Vehicle

The A18-13TJ Swampmaster Cherry Picker is designed for operators who need to reach locations which are inaccessible to other MEWP's for any work at height applications. It weighs 5.5 tonnes and benefits from having wide tracks, giving the machine a total ground contact area of 2.25m. This means the bearing pressure during travel is extremely low, making it ideal for wet or soft ground. The Yanmar C50 chassis has a travel speed of 9km/h with 30% gradeability and the machine can be levelled with hydraulic outriggers on a 20° transverse slope.

The tracked carrier has a fully enclosed heated cab with Roll Over Protection Systems and Fall Over Protection Systems (ROPS & FOPS), for potentially cold or remote locations. It also features an 18m work height ascendant platform which offers 13m of outreach and a 230kg safe working load to allow room for two operators and tools. The easy to position telescopic boom features a versatile 125° jib and the A18-13TJ Swampmaster is a standard production unit, featuring full pressure hydraulic controls for reliability in tough conditions as well as ease of maintenance. It is also fitted with a 6,000kg winch with spade-type anchor.

Key Features of the A18-13TJ Swampmaster

  • Direct hydraulic proportional controls at cage and base
  • 180 degree powered cage rotation
  • Four independently adjustable hydraulics stabilisers
  • Two section all steel telescopic boom
  • 2.1m long jib with 125 degree working arc
  • Structural quality tubular aluminium cage
  • Emergency lowering handpump
  • Heated, enclosed isolation-mounted RPOS/FOPS cab
  • Powerful 83kW 4-cylinder Yanmar diesel engine

Recommended training course for this platform: IPAF Category: Mobile Boom (1b)

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Cherry Pickers/Boom Lifts here.

  • Overhead power line installation, maintenance and repair
  • Slopes – both internal and external
  • Muddy, soft ground
  • Tunnelling
  • Horticulture
  • Arboriculture
  • Estate management

The A18-13TJ Swampmaster can be fitted-out with an assortment of accessories to increase productivity and safety on site.

Boom Lift Pipe Racks

Boom Lift Pipe Racks
Telematics

Telematics
Harness

Harness
Tool Tethers

Tool Tethers
Chalwyn Valves

Chalwyn Valves
Spark Arrestors

Spark Arrestors
Nappies

Nappies

The A18-13TJ Swampmaster comes equipped with various features designed to enhance your efficiency and performance on the job.

Diesel Powered

Diesel Powered
Steel Tracks

Steel Tracks
