Magni HTH 50.14

Magni HTH 50.14

Magni HTH 50.14

Specification

Make
Make
Magni
Model
Model
HTH 50.14
Lifting Height
Lifting Height
14m / 46ft
Maximum Outreach
Maximum Outreach
8m / 26ft 3in
Min Weight
Min Weight
68,000.00kg / 150,280lbs
Lifting Capacity
Lifting Capacity
50,000.00kg / 110,500lbs
Machine Length
Machine Length
10.705m / 35ft 2in
Machine Width
Machine Width
3.203m / 10ft 7in
Machine Height
Machine Height
3.8m / 12ft 6in
Power Options
Power Options
Diesel
Turning Radius
Turning Radius
9.6m / 31ft 6in
Gradeability
Gradeability
50%

Interested in hiring a Magni HTH 50.14?

ENQUIRE arrow icon Phone 0800 865 4455 Download Specification Download Specification
Key Features Accessories Ideal Applications Overview Resources

Magni HTH 50.14 Heavy Lift Telehandler

The Magni HTH 50.14 Telescopic Handler is ideal for moving large, bulky loads in complete safety. It is capable of lifting up to 50 tonnes and is compatible with a wide range of accessories, making it extremely versatile.

Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry and mining. Its four-wheel drive system, three manoeuvring modes and high ground clearance also make it highly manoeuvrable on all terrain types.

The comfort and 360° view offered by Magni’s patented cab also allow the operator to work under the optimum conditions, and help improve safety during delicate movements. It can move large blocks of marble or stone in quarries, or handle materials such as steel bars, rails or other metal structures. It is the ideal machine for maintenance of mining equipment, such as changing rails, replacing hammers or moving conveyor belts.

Key Features of the Magni HTH 50.14

  • Comfort seat
  • Adjustable steering column
  • Analogue joypad
  • Heating
  • Air conditioning
  • FM/AM radio with USB and Bluetooth connectivity
  • USB Type-A (5V) inputs
  • Touchscreen, 7”
  • MCTS – Magni Combi Touch System on-board software
  • Automatic RFID tools recognition system
  • LMI – Load Moment Indicator
  • Onboard and remote integrated diagnostics
  • Q-Fit Heavy-Duty
  • Two-line CAN BUS system
  • Automatic front and rear wheel alignment
  • Automatic parking brake
  • Mechanical battery cut-off in engine compartment
  • Electrical system: 24V – IP67

Available to hire, lease or buy from Hire Safe Solutions in the UK & ROI.

Call us on 0800 865 4455 for more information

Or, fill out an enquiry form here and we will get back to you as soon as possible.

Looking for something else?

Discover our entire range of Heavy Lift Telehandlers here.

  • Heavy Industry
  • Heavy Logistics
  • Quarries
  • Mining
  • Heavy power lift
  • Moving steel bars, rails etc.
  • Special Projects
